Aquaglide Arete 20

The all-new Arete 20 Aquapark provides an extended, lateral-climbing obstacle as users transit challenging ledges on each side!

Adds diversity to any aquapark in the large track footprint, while providing two needed bridges for ingress and egress of enclosed aquapark rings.

Use the Arete 20 as a standalone feature or connect it to other Aquaglide Aquapark features using the D-Ring Interloc system.

Arete 20' Waterpark Features

• Best for: climbing, playing, jumping, ingress/egress for enclosed rings

• Capacity: (3) Adults / (3) Children
• Dimensions: 20' L x 8.1' W x 6' H (3.05m x 2.46m x 1.83m)
• Minimum Water Depth: 6 Feet (1.82m)
• Includes: Storage Wrap, Repair Kit
• Not Included: Anchor Weights, Mooring Lines, Vario-Lock Straps, Inflation Pump

Waterpark Construction

• I-Beam: Rugged welded I-band construction with 3-layer seams
• Double I-Beam: Extra-reinforced, welded double-I-Beam construction with 3-layer seams
• Duratex Cx3: Premium commercial-grade material optimized for durability, weld strength and UV resistance
• Tritex Cx3: Uniquely textured version of our Duratex material adding grip and cooling attributes
• Interlock 5: 2 sets of secure and tamper-free 5-ring connections using our 2-Step Vario Strap system
• Halkey-Roberts valves: With tamper-proof cap for quick, effective inflation/ deflation
• PRV: Pressure relief valve to help protect against catastrophic over-inflation.

Key User Activities

• Climb: Multiple interior and exterior climbing routes

• Jump: Numerous jump areas add to the excitement!

• Bridge: Provides ingress and egress for floating rings


Technical Specifications

• Max Weight: 1000 lbs (454 kg)
• Material: 0.90 mm / 31 oz Cx3 PVC
• Minimum Distance from Shore: 10’ (3.0 m)
• Minimum Required Total Anchor Weight: 4,400 lbs (2000 kg)
• Anchor Rings: 4
• Accessory Attachment D-rings: 5 each, on 2 ends

Product Notes

Weight Recommendations

Weight recommendations are for anchoring in conditions with extreme weather, waves, or other abnormal conditions. Aquaglide recommends contacting a dock and mooring specialist for anchor installation options and assistance

Disclaimer

Aquapark products are not authorized for use in combination with products or attachments from any other manufacturer. Aquaglide product combinations must be authorized or approved in advance by the manufacturer. Use of Aquaglide products in combination with products from other manufacturer and/or product arrangements not approved by Aquaglide may result in increased risk of entrapment, injury, or death.
